GEPRC TAKER F405 BLS 100A 8S STACK for 13inch drone

Changelog

Oct 20, 2025:

The flight control firmware has been changed to: [GEPRCF405_8S]. If you continue to use the [GEPRCF405_BT_HD] firmware for burning, you need to enter the following command in the CLI after burning the firmware:

resource SERIAL_TX 11 NONE
resource SERIAL_RX 11 NONE
set pinio_config = 1,1,1,1
set pinio_box = 32,41,255,255
save

Features

1. Use mainstream STM32F405 chip
2. Equipped with the latest 42688-P gyroscope
3. 16M black box storage
4. Integrated LC filter
5. Upgrade type-C USB interface
6. Directly plugged into the DJI Air Unit
7. With TAKER H100_8S_BLS 100A 4IN1 ESC, Dual MOS, high current, silky flight
8. Supports 8S Lipo battery
9. Simple and reasonable installation method, the shock absorber can make the gyroscope work very stably
10. 12V@3A + 5V@3A dual independent BEC

Specifications

GEP-F405-8S Flight Controller

• MCU: STM32F405
• IMU: ICM42688-P(SPI)
• Air Unit Connection: Direct plugging into DJI Air Unit
• Black Box: 16M onboard
• Barometer: support
• Motor outputs: M1-M8
• USB Interface: Type-C
• OSD: BetaFlight OSD w/ AT7456E chip
• BEC: 5V@3A,12V@3A dual BEC
• Firmware Target: GEPRCF405_8S
• Size: 37x37mm
• Mounting: 30.5×30.5mm??4mm hole becomes ?3mm after using a silicone shock-absorbing circle
• Input Voltage: 3-8S LiPo
• UART: 6 UARTs
• Power Filter: Integrated LC filter
• Weight: 8.3g

TAKER H100_8S_BLS 100A 4IN1 ESC

• Input Voltage: 3-8S Lipo
• Ammeter: Support
• Calibration value: 200
• Continue Current: 100A
• Burst Current: 105A?5 second?
• Support Protocol: Dshot 150/300/600
• Size: 56.3*61.1mm?hole30.5×30.5mm??4mm hole becomes ?3mm after using the silicone shock-absorbing ring.
• Weight: 28.8g
• Target: B_X_3

Includes

1 x GEP-F405-8S Flight Controller

1 x TAKER H100_8S_BLS 100A 4IN1 ESC

1 x Electrolytic capacitor(50V 4700uF)

1 x DJI connection cable(SH1.0 6pin 100mm)

2 x FC adapter cable(SH1.0 8pin 30mm)

1 x Receiver silicone cable(SH1.0 4pin 150mm)

1 x Camera connection cable(SH1.0-SH1.25 3pin 135mm)

1 x VTX connection cable(SH1.0 4pin-6pin 100mm)

1 x XT90 battery plug

1 x Red and black power cable(10AWG 240mm)

4 x M3*30 screws

4 x M3*25 screws

8 x Nylon nuts(M3)

12 x Silicone anti-shake pads(M3)
