Feature
3115 series motors are mainly designed for long range FPV.
High-strength M5 steel shaft
High torque magnetic circuit design
19mmx19mm base
Specifications
Model: 3115 900KV Motor
Max Watt: 1705W
Peak current: 68.2A
Interphase resistance: 46m
Propeller: 8-10inch Propeller
Magnet: N52H
Configuration: 12N14P
Dimension: ?37.5mmx30mm
Shaft Diameter: ?5mm
Shaft Protruding Length: 16mm
Mounting holes: 19mmx19mm
Lead: 310mm/18AWG
ESC: 60A-80A
Input Volts: 25.2V?6S LiPo)
Winding: Single strand copper winding
Weight: 115g(included wire)
Suitable for :8-10 inch long range FPV
Includes
4 x 3115 motor
16 x M3*11 round head screws
4 x M5 anti-slip nut
